92系列图片请点击
先导式四通阀.接口1/8"～3/8"。MAC独有的四通先导提供了强大的换向力,且换向阻力极小。
可叠加调压阀，可支持双压力，可叠加流量调节阀。
拥有MAConnect电连接方式和阀岛组合。
有气控阀选择。可选择插入式接线，电连接更安全。
有本质防爆阀
 （点击中文资料）
The MAC 92 Series is a 4-way spool valve pilot
operated by a small direct operated 4-way solenoid valve - a one-off
in air valve manufacturing. The 4-way pilot means a low minimum
operating pressure - no pistons - and minimal resistance to
shifting. The balanced design in the pilot means shifting forces are
consistently high and response times are repeatable regardless of
inlet pressure fluctuations. For more information regarding
certifications (such as UL, CSA, RoHS and CE) please visit the Get
Support pages on our website.
Application, Installation and Service
Precautions
Cv (Max): 1.2
Port Sizes: 1/8"-3/8"
Configurations: Individual Sub base/Manifold: Plug-in/Non Plug-in
92 Series Catalog Pages
92 Series Circuit Bar Pages
92 Series Regulator Pages
92 Series Remote Air Pages
92 Series Intrinsically Safe Pages
82/92 Series MAConnect Pages（英文详细资料请点击下载）
|
